Tiny size Rotation Sensor Switch

  • Tiny size Rotation Sensor Switch
  • Tiny size Rotation Sensor Switch
  • Tiny size Rotation Sensor Switch
RBS100601 / RBS100611T
Function: Rotation detection at 45° in vertical position
Certification: RoHS,REACH,Patent
Original Place: Taiwan

Please select which you want to ask the following product specifications:


Model RBS100601
Operating Angle 45°
Switch State
DIP Normal Close
SMD Normal Close
Dimension (mm)
PCB direction
Vertical PCB Vertical PCB
IR Reflow
Peak temp.=255~260℃

Electrical Characteristics

  • Contacting Rate: 10mA, 5VDC
  • Contact Resistance: 50 Ω max.
  • Insulation Resistance: 50 MΩ min. at 100 VDC
  • Dielectric Strength:50VDC min. for 1 minute
  • Capacitance: 5pF max.

Reliable Test Items

  • Operating Temperature:-25°C ~ 85°C
  • Storage Temperature:-40°C ~ 85°C
  • Humidity: 40°C / 95%RH
  • Mechanical Life: 2HZ,horizontal  1,000,000 times
  • Electrical Life: 100,000 times

Current/Voltage Suggested

Input Current (mA)
Operating Voltage (V)
1.0 5~12 --

  • Function: Rotation detection at 45° in vertical position.
  • Small size & compact space.
  • Housing made of high insulation plastic material, free from electric conduction and rust problem.
  • Terminals and balls are gold plated to enhance the life.
  • All plastic material subject to industrial purpose meets high temperature and fireproof function.
  • Simple switch signal, easy for circuit design.
  • Comply with RoHS, complete replacement of mercury switch and meet environmental protection.
  • More economic than IC design.
  • Do not try to clean the switch with a solvent or similar substance after the soldering process.
  • All made in Taiwan and Examined before shipment.
  • Suggestion for usage: For vibration usage or application, we suggest to add hysteresis for IC; if vibration is heavy, optical type of sensor switch is recommended.
  • For the continued product improvement as one of the company policy, specifications may change or update without notice. The latest information can be obtained through our sales offices. Normally, all products are supplied under our standard conditions.

As for the Roll Ball Switches, a tiny ball in the switch rolls when motion is detected, triggering a contact of metal terminals. This will generate the conductive or non-conductive status.They provide accurate control for a wide variety of applications like auto shut-off for home appliances, powering saving function, anti-theft security system, any angle change detecting and so on.

Case of RBS10 series


Function : Auto Screen On When Lifting Wrist
Model :
RBS100601 / RBS100611T
