One Way 15° Angle sensor for Horizontal & Reverse mount PCB

  • One Way 15° Angle sensor for Horizontal & Reverse mount PCB
  • One Way 15° Angle sensor for Horizontal & Reverse mount PCB
  • One Way 15° Angle sensor for Horizontal & Reverse mount PCB
Please select which you want to ask the following product specifications:
● Function: One Axis 15° tilt Detecting in horizontal position(installed above or under PCB)
● Description:Ball-Contact
● RBS151100 / RBS152100T
● Certification: RoHS,REACH,Patent
● Original Place: Taiwan
※ Please refer to the specifications for the manufacturing process and other precautions




Model
RBS151100
RBS152100T
Operating Angle
15°
15°
Switch State
DIP Normal Open
SMD Normal Open
Dimension(mm)
6*5*7
6*5*7
PCB direction
Horizontal PCB
Horizontal PCB
 IR Reflow
--
 Peak temp.=255~260℃


Electrical Characteristics

  • Contacting Rate: 10 mA, 5VDC
  • Contact Resistance:10 Ω max.
  • Insulation Resistance: 10 MΩ min. at 100 VDC
  • Dielectric Strength:500VDC min. for 1 minute
  • Capacitance: 5 pF max.


Reliable Test Items

  • Operating Temperature: -25°C ~ 85°C
  • Storage Temperature: -40°C ~ 85°C
  • Humidity: 40°C / 95%RH
  • Mechanical Life:2HZ,horizontal  1,000,000 times
  • Electrical Life:100,000 times


Current / Voltage Suggested

Input Current (mA)
Operating Voltage (V)
Condition
1.0 5 --

  • Function: One Axis 15° tilt Detecting in horizontal position installed above or under PCB.
  • Housing made of high insulation plastic material, free from electric conduction and rust problem.
  • Gold-plated ball and terminals, low possibility of oxidization.
  • All plastic materials subject to industrial purpose, resist high temperature and meet fireproof function.
  • Simple ON and OFF signals, easy for design.
  • RoHS compliance, an ideal substitute for mercury switch.
  • A more economical tilt and rotation detection option than IC design solution.
  • All made in Taiwan and examined before shipment.
  • Do not try to clean the switch with a solvent or similar substance after the soldering process.
  • Suggestion for usage: For vibration usage or application, we suggest to add hysteresis for IC; if vibration is heavy, optical type of sensor switch is recommended.
  • For the continued product improvement as one of the company policy, specifications may change or update without notice. The latest information can be obtained through our sales offices. Normally, all products are supplied under our standard conditions.

As for the Roll Ball Switches, a tiny ball in the switch rolls when motion is detected, triggering a contact of metal terminals. This will generate the conductive or non-conductive status.They provide accurate control for a wide variety of applications like any angle change detecting or vibration detecting and so on.


Case of RBS15 series





Remote Control

Function :  Automatic Start Up

Model: RBS151100



Electric Car Key

Function :  Automatic Start Up

Model : RBS151100
